Radian - Flight Controller
מחיר רגיל
460.00 ₪
מחיר ליחידה
/
לא זמין
Introducing the Radian Flight Controller, a premier flight control system designed for seamless compatibility with ArduPilot, PX4 and Betaflight firmware and with full Pixhawk standard compatibility. Engineered for superior performance and versatility, the Radian Flight Controller is the perfect solution for a broad spectrum of UAV applications, from recreational drones to complex commercial and industrial operations.
Key Features
- Dual Firmware Compatibility: The Radian supports both ArduPilot and PX4 firmware, providing the flexibility to select and switch between two leading autopilot platforms to best suit your project requirements.
- Advanced Sensor Suite: Equipped with dual 9-axis IMUs (gyroscope, accelerometer, magnetometer), a high-resolution barometer. in addition, all sensors and dual redundant. the Radian offers accurate and stable navigation in various flight conditions.
- Extensive Connectivity Options: With multiple I/O ports including UART, I2C, SPI, CAN, and PWM, the Radian supports a wide array of peripherals such as cameras, gimbals, telemetry modules, and additional sensors.
- Robust Power Management: Featuring an integrated power management system with redundant power inputs and protection circuits, the Radian ensures reliable operation even in demanding environments while supporting up to dual 14S input.
- Compact and Lightweight Design: The Radian's optimized PCB layout and compact form factor make it suitable for a variety of UAV platforms, including multirotors, fixed-wing aircraft, and VTOLs.
- User-Friendly Setup: The Radian comes with pre-configured settings and detailed documentation for a quick and easy setup process, supported by a wealth of community resources for troubleshooting and customization.
Specifications
- Processor Variants: STM32F405RG (Cortex-M4 @ 168 MHz, 1 MB Flash, 192 KB SRAM), STM32H743 (Cortex-M7 @ 480 MHz, 2 MB Flash, 1 MB SRAM)
- IMUs: Bosch BMI270, TDK ICM42688P
- Barometers: Bosch BMP280, ST LPS22HBTR
- Compasses: Bosch BMM150, ST LIS3MDL
- Power Input: Dual redundant inputs up to 60 V (3S–14S LiPo), integrated dual eFuse, voltage sensing, onboard DC-DC conversion
- Mounting Holes: M3 (30.5 X 30.5 mm)
- Dimensions: 38 X 46 mm
- Weight: 19 g
- Input Voltage: 7-60 V
Included in the Box
-
1 × Radian Flight Controller Unit
-
1 × Radian Carrier
-
1 × Cable Kit
-
1 × FCU Plastic Enclosure
