H743 Flight Controller ArduPilot, and Betaflight firmware

Name: H743 Flight Controller ArduPilot, and Betaflight firmware
Brand: ReadyEdi
Price: 165.00 ILS
Availability: InStock

165.00 ₪

כולל מע״מ עלות משלוח מחושבת במהלך התשלום.

🛠️ למידע נוסף ועיון במפרט המלא

Ardupilot Firmware

Introducing the H743 Flight Controller, a premier flight control system designed for seamless compatibility with ArduPilot, PX4 and Betaflight firmware and with full Pixhawk standard compatibility. Engineered for superior performance and versatility, the Flight Controller is the perfect solution for a broad spectrum of UAV applications, from recreational drones to complex commercial and industrial operations.

Key Features

Dual Firmware Compatibility: The FC H743 supports both ArduPilot and PX4 and Betaflight firmware, providing the flexibility to select and switch between two leading autopilot platforms to best suit your project requirements.
Advanced Sensor Suite: Equipped with dual 9-axis IMUs (gyroscope, accelerometer, magnetometer), a high-resolution barometer. in addition, all sensors and dual redundant. the H743 Flight Controller offers accurate and stable navigation in various flight conditions.
Extensive Connectivity Options: With multiple I/O ports including UART, I2C, SPI, CAN, and PWM, the H743 Flight Controller supports a wide array of peripherals such as cameras, gimbals, telemetry modules, and additional sensors.
Robust Power Management: Featuring an integrated power management system with redundant power inputs and protection circuits, the H743 Flight Controller ensures reliable operation even in demanding environments while supporting up to dual 14S input.
Compact and Lightweight Design: The H743 Flight Controllers optimized PCB layout and compact form factor make it suitable for a variety of UAV platforms, including multirotors, fixed-wing aircraft, and VTOLs.
User-Friendly Setup: The comes with pre-configured settings and detailed documentation for a quick and easy setup process
Features
- MCU - STM32H743 32-bit processor running at 480 MHz
- IMU - Dual ICM42688
- Barometer - SPL06
- OSD - AT7456E
- Onboard Flash: 16MByte
- 8x UARTs
- 1x CAN port
- 13x PWM Outputs (12 Motor Output, 1 LED)
- Battery input voltage: 4S-12S
- BEC 3.3V 0.5A
- BEC 5V 3A
- BEC 12V 3A for video, gpio controlled
- Dual switchable camera inputs

Specifications

Power Input: Dual redundant inputs up to 54 V (3S–12S LiPo), integrated dual eFuse, voltage sensing, onboard DC-DC conversion
Mounting Holes: M3 (30.5 X 30.5 mm)
Dimensions: 38 X 46 mm
Weight: 19 g
Input Voltage: 7-54 V

Included in the Box

1 × Flight Controller Unit
1 × Cable Kit
